The Ingress resource type was introduced in Kubernetes version 1.1. The Kubernetes cluster must have an Ingress controller deployed in order for you to be able to create Ingress resources. What is the Ingress controller? The Ingress controller is deployed as a Docker container on top of Kubernetes. Its Docker image contains a load balancer like nginx or HAProxy and a controller daemon. The controller daemon receives the desired Ingress configuration from Kubernetes. It generates an nginx or HAProxy configuration file and restarts the load balancer process for changes to take effect. In other words, Ingress controller is a load balancer managed by Kubernetes.


Ingress resources don't do anything by themselves: they are processed by ingress controllers, which vanilla Kubernetes does not provide by default.


Ingress vs Loadbalancer service

The difference between the LoadBalancer service and the Ingress in how the traffic routing is realized. In the case of the LoadBalancer service, the traffic that enters through the external load balancer is forwarded to the kube-proxy that in turn forwards the traffic to the selected pods. The Ingress load balancer forwards the traffic straight to the selected pods which is more efficient.

Ingress object

Example below has been fetched from Minikube stern nginx --all-namespaces nginx

kube-system ingress-nginx-controller-xx controller ------------------------------------------------------------
kube-system ingress-nginx-controller-xx controller NGINX Ingress controller
kube-system ingress-nginx-controller-xx controller   Release:       0.32.0
kube-system ingress-nginx-controller-xx controller   Build:         git-446845114
kube-system ingress-nginx-controller-xx controller   Repository:    https://github.com/kubernetes/ingress-nginx
kube-system ingress-nginx-controller-xx controller   nginx version: nginx/1.17.10
kube-system ingress-nginx-controller-xx controller ------------------------------------------------------------


$ kubectl get ingresses ingress-with-auth -oyaml

apiVersion: extensions/v1beta1
kind: Ingress
metadata:
  annotations:
    kubernetes.io/ingress.class: nginx # useful annotation
    nginx.ingress.kubernetes.io/auth-realm: Authentication Required - foo
    nginx.ingress.kubernetes.io/auth-secret: basic-auth
    nginx.ingress.kubernetes.io/auth-type: basic
  name: ingress-with-auth
  namespace: default
spec:
# backend: # <Object> default backend
    serviceName: # <string>
    servicePort: # <string>
  rules: # <[]object> list of host rules, if not specified sent to default backend
  - host: echo-1.ingress.k8s.acme.cloud # fqdn of a network host, IPs are not allowed
    http:                               # `:` is not respected because ports are not allowed
      paths:                            # currently the port of an Ingress is http:80 and :443 for https
      - backend:
          serviceName: http-svc
          servicePort: 80
        path: /
# tls: # <[]Object> TLS configuration, currently supports a single TLS port:443
# - secretName: tls-certificate # secret used to terminate SSL traffic on 443
#   hosts: # optional rules.host is used if unspecified; must match names in tlsSecret
#   - echo-1.ingress.k8s.acme.cloud
status:
  loadBalancer:
    ingress:
    - ip: 172.17.0.2 # Kubernetes API server IP
                     # public IP address on which this Ingress is available
                     # this is nginx-controller pod (leader) node IP

Status.Address update is a background goroutine that runs once a minute, queries the IP address of the node on which the Nginx ingress controller is running, and simply updates the Status.Address to that value.


Simple /etc/hosts entry will make your local machine to access an application exposed via Ingress

172.17.0.2 echo-1.ingress.k8s.acme.cloud


Interesting fact is that the ingress IP is actually the leader pod node's ip

$ kubectl get nodes -owide
NAME           STATUS ROLES  AGE  VERSION  INTERNAL-IP EXTERNAL-IP OS-IMAGE     KERNEL-VERSION   CONTAINER-RUNTIME
minikube-v1.15 Ready  master 172m v1.15.11 172.17.0.2  <none>      Ubuntu 19.10 5.3.0-59-generic docker://19.3.2

$ minikube ssh # ssh to Kubernetes node
docker@minikube-v1:~$ ip a | grep "inet "
    inet 127.0.0.1/8 scope host lo
    inet 172.18.0.1/16 brd 172.18.255.255 scope global docker0
    inet 172.17.0.2/16 brd 172.17.255.255 scope global eth0     # <- K8s node ip


The ingress-nginx-controller pod exclusively binds to listen on ports :80 and :443 on the node is running

# $ minikube addons enable ingress # Running
$ sudo ss -lntp | tail +1 | sort -k4
State  Recv-Q Send-Q Local Address:Port  Peer Address:Port
LISTEN 0      128                *:10250            *:*   users:(("kubelet",pid=5342,fd=28))
LISTEN 0      128                *:10251            *:*   users:(("kube-scheduler",pid=6070,fd=3))
LISTEN 0      128                *:10252            *:*   users:(("kube-controller",pid=6023,fd=3))
LISTEN 0      128                *:10256            *:*   users:(("kube-proxy",pid=6679,fd=10))
LISTEN 0      128                *:2376             *:*   users:(("dockerd",pid=88,fd=6))
LISTEN 0      128                *:30012            *:*   users:(("kube-proxy",pid=6679,fd=14))
LISTEN 0      128                *:30932            *:*   users:(("kube-proxy",pid=6679,fd=13))
LISTEN 0      128                *:32392            *:*   users:(("kube-proxy",pid=6679,fd=11))
LISTEN 0      128         # ->   *:443              *:*   users:(("docker-proxy",pid=8486,fd=4)) # <- added by nginx-controller
LISTEN 0      128         # ->   *:80               *:*   users:(("docker-proxy",pid=8505,fd=4)) # <- added by nginx-controller
LISTEN 0      128                *:8443             *:*   users:(("kube-apiserver",pid=5917,fd=3))
LISTEN 0      128             [::]:111           [::]:*   users:(("rpcbind",pid=77,fd=6),("systemd",pid=1,fd=47))
LISTEN 0      128             [::]:22            [::]:*   users:(("sshd",pid=89,fd=4))
LISTEN 0      128             [::]:37289         [::]:*   users:(("rpc.statd",pid=3050,fd=11))
LISTEN 0      128          0.0.0.0:111        0.0.0.0:*   users:(("rpcbind",pid=77,fd=4),("systemd",pid=1,fd=45))
LISTEN 0      128          0.0.0.0:22         0.0.0.0:*   users:(("sshd",pid=89,fd=3))
LISTEN 0      128          0.0.0.0:39729      0.0.0.0:*   users:(("rpc.statd",pid=3050,fd=9))
LISTEN 0      128        127.0.0.1:10248      0.0.0.0:*   users:(("kubelet",pid=5342,fd=21))
LISTEN 0      128        127.0.0.1:10257      0.0.0.0:*   users:(("kube-controller",pid=6023,fd=5))
LISTEN 0      128        127.0.0.1:10259      0.0.0.0:*   users:(("kube-scheduler",pid=6070,fd=5))
LISTEN 0      128        127.0.0.1:2379       0.0.0.0:*   users:(("etcd",pid=5867,fd=5))
LISTEN 0      128        127.0.0.1:2381       0.0.0.0:*   users:(("etcd",pid=5867,fd=10))
LISTEN 0      128        127.0.0.1:38999      0.0.0.0:*   users:(("kubelet",pid=5342,fd=9))
LISTEN 0      128        127.0.0.1:40073      0.0.0.0:*   users:(("containerd",pid=87,fd=8))
LISTEN 0      128       172.17.0.2:10249      0.0.0.0:*   users:(("kube-proxy",pid=6679,fd=12))
LISTEN 0      128       172.17.0.2:2379       0.0.0.0:*   users:(("etcd",pid=5867,fd=6))
LISTEN 0      128       172.17.0.2:2380       0.0.0.0:*   users:(("etcd",pid=5867,fd=3))
LISTEN 0      128       172.17.0.2:2381       0.0.0.0:*   users:(("etcd",pid=5867,fd=12))

Nginx ingress controller



Events changes watch

Nginx controller listens for events on the following resource types changes:

  • Ingresses
  • Endpoints
  • Secrets
  • ConfigMaps


Events get into the queue represented by controller.syncQueue and the internal/ingress/controller/controller.go queue handler function, function syncIngress(). This function collects all necessary information to regenerate the Nginx config file: it fetches all relevant Ingress objects and looks up associated Pods' IP addresses that the Ingresses should route to.


Build new configuration and reload

syncIngress() then calls internal/ingress/controller/nginx.go function OnUpdate() to actually write out the new Nginx config file and to reload Nginx.


Ingress Status.Address determination

A background goroutine which, once a minute, queries the IP address of the node on which the Nginx ingress controller is running, and simply updates the "Status.Address" to that value. With multiple controller pods running, the leader's IP is used.


Not using Services

ingress-nginx-controller does not route traffic to the associated Service's virtual IP address. Instead it routes directly to the pods' IP addresses, using the endpoints API Resources. This allows for session affinity, custom load balancing algorithms, less overhead, such as conntrack entries for iptables DNAT.
